Multipurpose High Performance 12″ Coax
600W/8ohm – 128dB SPL
Features
- 12″ coaxial woofer with 2.5″ coil and 1″ HF driver with 1.7″ coil on conical 90° horn
- 100V line transformer with selectable 200W/100W power tapping
- Sturdy molded polyethylene curved enclosure
- 4 wires cable to select the desired power tapping
- Water-stop grill with 3 layers of protection
- IP55 weather resistant
- Standard grey finish
- RAL 7011
Specifications
| Code: | 36194 |
|---|---|
| Configuration: | 2 way |
| Recommended amplifier: | 600 W RMS |
| Long Term power: | 300 W |
| Short term power: | 1200 W |
| Transformer: | 100/200 V |
| Nominal impedance: | 8 ohm |
| Frequency response: | 70Hz – 20Khz -6dB |
| Low Frequency woofer: | 12 – 2.5 coil inch |
| AES power: | 250 W |
| High frequency driver: | 1 – 1.7 coil inch |
| Sensitivity (@1W/1m): | 98 dB |
| Maximum SPL cont/peak: | 124/128 dB |
| Dispersion: | 90° conical HxV |
| Crossover Frequency: | 1.6 KHz |
| Recommended HP filter: | 50hz – 24dboct |
| Input connector: | 4 wire cable |
| Net Dimension (WxHxD): | 430x430x400 – 16.92×16.92×15.74 mm/inch |
| Net Weight: | 15/33 kg/lb |
| Transport Dimension (WxHxD): | 530x530x500 – 20.86×20.86×19.68 mm/inch |
| Transport Weight: | 17/37 kg/lb |
