Specifications:

Code: 26937
Configuration: 2 way
Built-in amplifier LF/HF: 1000/250 W RMS
Built-in amplifier peak LF/HF: 2000/500 W
Frequency response: 45Hz – 20kHz -6dB
Low Frequency woofer: 1×12 – 3 coil inch
High Frequency driver: 1 – 1.7 coil inch
Maximum SPL cont/peak: 127/133 dB
Dispersion: 90° x 60° HxV
Input impedance: 22 Kohm
Crossover Frequency: 1.6 KHz
Input connector: XLR/jack with loop RCA aux
Power cord: 5 / 16.4 m/ft
Net Dimension (WxHxD): 407x634x370 – 16×24.9×14.5 mm/inch
Net Weight: 17.9 / 39.4 Kg/lb
Transport Dimension (WxHxD): 495x720x470 – 19.5×28.3×18.5 mm/inch
Transport Weight: 20.5 / 45.2 Kg/lb

Click here to download FBT Himaxx40a brochure

With the new HiMaxX series, FBT establishes a reference point on the scenario of 12” and 15” enclosures in polypropylene for sound reinforcement, introducing performance and technical content of a standard unthinkable up until now. FBT HiMaxX takes its place alongside the FBTMaxX series, exalting all the technical features.

The study of a new cabinet in polypropylene, the use of a switch mode power supply and high efficiency power amplifiers and the redesign of the loudspeakers were the activities of the FBT R&D team aimed at maximizing the power weight ratio.

This series comprises three models; two 2-way full-range enclosures in polypropylene, HiMaxX 40 (12”+1”) and HiMaxX 60 (15’’+1.4”), plus a compact  18’’ bandpass SUB in birch plywood (HiMaxX 100Sa).

Compact and light weight, HiMaxX brilliantly solve all the most demanding requests from buffs, musicians and professionals looking for powerful, versatile and very high quality loudspeaker enclosures. Ideal for live and sound reinforcement applications requiring ease of transport, they are also suited to fixed installations, thanks to the cabinets’ format and optional accessories.
