GA335 3-Channel Commercial 35 Watt Mixer/Amplifier
GA335 3-Channel Commercial 35 Watt Mixer/Amplifier
PHENOMENAL POWER IN A HALF-RACK CONSTRUCT
For commercial installations and set ups, the Asystems GA series of mixer/amplifiers provide the power and precision necessary for a flawless system. The GA335 provides a total of 3 inputs with a 35W amplifier output. Each GA mixer/amplifier also features an individual level control on each input, voice activated muting, music on hold output and bass and treble controls. Offering a myriad of professional inputs possibilities and flexible output modes including 70V and 100V, the GA series of mixer/amplifiers is perfect for background music, broadcast paging, as well as on-hold music for offices, restaurants, factories and churches.
Features
|
|
Specifications
| GA335 | |
| Power Output (Peak) | 35W |
| Input Section | |
| RCA Input | 2 |
| Frequency Response | 70Hz to 18kHz ±2dB |
| Euroblock Input | 1 |
| Output Section | |
| Balanced Screw Terminal Output | Yes |
| Balanced Euroblock Output | Yes |
| Zone 2 (Telephone Use) | Yes |
| 70V Output | Yes |
| 100V Output | Yes |
| S/N Ratio | All>60dB |
| Input Signal LED | Yes |
| Master Out Clip LED | Yes |
| Treble & Bass (Output) | Yes |
| VOX Threshold | Yes |
| Number of Input Channels | 3 |
| Input Volume Control | 3 |
| Master Out Level Control | 1 |
| THD@ 1kHz (10% Rated Output) | < 0.5% |
| Phantom Power | 14~15V |
| Dimensions (WxHxD) | 241 x 105 x 352 mm (9.49” x 4.13” x 13.86”) |
Click here to download Asystems GA335 GA460 brochure
Click here to download Aystems GA335_GA460 user manual
