Fetatures:
- Impulsive power with both channels driven:
- 2 x 600W (8 ohm)
- 2 x 1000W (4 ohm)
- 2 x 1500W (2 ohm).
- Continuous power with both channels driven:
- 2 x 550W (8 ohm)
- 2 x 900W (4 ohm)
- 2 x 1300W (2 ohm)
- Electronically balanced inputs
- 4-way Speakon power outputs and binding posts
- Option of parallel, mono and stereo operation
- Power supply protection with miniature circuit breaker
- Independent protection on each channel
- Soft start
- Delayed output connection
- Double DC protection for speakers (relays)
- Output short-circuit protection
- SOA protection
- Clipping limiter
- 8 bi-colour LEDs indicating all operating modes
- Ground lift switch
- Signal/noise ratio S/N under 110 dB weighting curve “A”
- Frequency response 20Hz – 20kHz
- Dimensions (WxHxD) 482x88x460 mm
- Weight 24 kg
Click Here to Download fbt-power-amplifier-symbol-12000 PDF
