Specifications:
| Code: | 33274 |
| Configuration: | 2 way |
| Recommended amplifier: | 600 W RMS |
| Long Term power: | 300 W |
| Short term power: | 1200 W |
| Nominal impedance: | 8 ohm |
| Frequency response: | 55hz – 18KHz -6dB |
| Low Frequency woofer: | 1×12 – 3 coil – neodymium inch |
| High frequency driver: | 1 – 1.4 coil-neodymium inch |
| Sensitivity (@1W/1m): | 99 dB |
| Maximum SPL cont/peak: | 126/130 dB |
| Dispersion: | 90°x60° HxV |
| Crossover Frequency: | 1.6 KHz |
| Recommended HP filter: | 45hz – 24dboct |
| Input connector: | 2 x speakon NL4 in & thru |
| Net Dimension (WxHxD): | 402x745x440 / 15.8×25.4×13.6 mm/inch |
| Net Weight: | 14.4 / 38.7 kg/lb |
| Transport Dimension (WxHxD): | 500x745x440 / 19.7×29.3×17.3 mm/inch |
| Transport Weight: | 17.4 / 38.3 kg/lb |
