SYM-18000
p5

Features:

  • Impulsive power with both channels driven:
    • 2 x 800W (8 ohm)
    • 2 x 1500W (4 ohm)
    • 2 x 2400W (2 ohm)
  • Continuous power with both channels driven:
    • 2 x 700W (8 ohm)
    • 2 x 1300W (4 ohm)
    • 2 x 1800W (2 ohm)
    • XLR signal inputs and outputs
    • Electronically balanced inputs
    • 4-way Speakon power outputs and binding posts
    • Option of parallel, mono and stereo operation
    • Power supply protection with miniature circuit breaker
    • Independent protection on each channel
    • Soft start
    • Delayed output connection
    • Double DC protection for speakers (relays)
    • Output short-circuit protection
    • SOA protection
    • Clipping limiter
    • 8 bi-colour LEDs indicating all operating modes
    • Ground lift switch
    • Signal/noise ratio S/N under 110 dB weighting curve “A”
    • Frequency response 20Hz – 20kHz
    • Dimensions (WxHxD) 482x88x460 mm
    • Weight 28 kg

Click Here to Download fbt-power-amplifier-symbol-18000 PDF
